AUDIO

4TOMS

340€/150€(KIT)


To buy, see DEALERS , or simply send an email: LARIX ELEKTRO

IMG 1
IMG 2
IMG 3
IMG 4
IMG 1
IMG 2
IMG 3
IMG 4

WHAT'S THAT THING ?
The 4TOMS is a set of four percussive voice with a full stereo mixer. It can generate a lot of various drums, and even kick drum or rimshot.
But the module can go further:
- Bell like sounds with the CV controle.
- Gentle drums, or very dirty saturated sounds.

Each voice has four parameters :
Tune, Tone, Accent and Decay.
Tune, Accent and Decay are CV controlable.
The stereo mixer provides volume and pan for each voice.

Voices 1 & 3 have a lower pitch than 2 & 4.
Voices 1 & 2 are normalled, as voices 3 & 4.
It allows to build more complexe drums.

A CUT input forces the signal to zero. (as applying the hand on the Drum Skin to stop the sound)

A lot of options are available on the back:
Selection of the CV input (or adding more input)
All critical capacitors are through Holes, to allows easy modifications.
Technical specifications:
+12V : 110mA (180mA when Decay is at minimum for all toms)
-12V : 100mA
20HP, 35mm deep (Approx.)
Package Contents
The module, wrapped in antistatic protection.
Four M3 screws.
The power cable.
Quick start map of the module.
Package Contents (Kit):
Front Panel + 3 PCB (MAIN + 2voices)
wrapped in antistatic protection.
Quick start map of the module.
User manual: AUDIO 4TOMS
Extensions, How to: AUDIO 4TOMS EXTENSIONS
Build doc (KIT version): AUDIO 4TOMS BUILD

Extensions:
Adding attenuverting control to 4 more CV: CONTROLE AttV-4
Or without attenuverter: CONTROLE Mult.
